Description
Feature |
Specification / Advantage |
Sensor & image quality |
640×480 pixel uncooled microbolometer, with a pixel spacing (pitch) of 17 µm; NETD value < 18 mK for very good sensitivity. Pulsar Vision+2jachtxl.nl+2 |
Lens / Objective |
F50 / F1.0 germanium lens, suitable for long range and good low-contrast performance. Hemker&Bekking+2jvs-outdoor.eu+2 |
Magnification & Field of vision |
Optical magnification of 2,5-10×, with additional digital zoom; field of view approx. 12.4×9.3° (horizontal × vertical) - at 100 m this translates to some 21.8×16.3 metres. Pulsar Vision+2The Paander+2 |
Detection distance |
Up to approx. 1,800 metres for medium-sized objects (e.g. human figure) under good conditions. jvs-outdoor.eu+2Pulsar Vision+2 |
Laser rangefinder (LRF) |
Integrated LRF with measuring range up to 1,000 metres, accuracy ±1 metre. Hemker&Bekking+3Pulsar Vision+3jachtxl.nl+3 |
Display & recording |
AMOLED HD display with resolution 1,024×768 pixels. Internal memory 64 GB for photos and videos; ability to record. Waermebild24.com+3Pulsar Vision+3waidmann-shop.com+3 |
Battery & power supply |
Removable Li-ion battery ("LPS 7i"), operating time approx. 8-8.5 hours at approx. 22 °C. Charging via USB Type-C, compatible with USB Power Delivery. Some modes support wireless charging. Pulsar Vision+2Hemker&Bekking+2 |
Construction & sustainability |
Housing with rubber armouring, IPX7 waterproofing (protection against immersion, rain) and operation in temperatures from -25 °C to +40 °C. Ergonomic design; symmetrical operation makes use comfortable for both left- and right-handers. jachtxl.co.uk+2waidmann-shop.com+2 |
Additional functions |
Wi-Fi, Stream Vision app support, different colour palettes, digital zoom, symmetrical button layout, option and sensor modules upgradeable in future versions. jachtloods.nl+3jachtxl.nl+3jvs-outdoor.eu+3 |
Applications
-
Hunting/wildlife observation: for detection and identification of animals, even at longer distances in low light or at night.
-
Security/surveillance work: because it combined detection, distance measurement and recording.
-
Hiking and outdoor activities: navigation, orientation, spotting objects in dark environments.
-
Professional use under changing conditions (fog, rain, cold) thanks to robust construction.
Benefits & concerns
Advantages
-
Very high image quality due to good sensor & lens.
-
Detection on distant objects.
-
Laser rangefinder makes target estimation more accurate.
-
Long battery life, removable battery, modern charging options.
-
Upgrade capabilities → device remains relevant over time.
-
IPX7 and hefty temperature range → reliability in rough terrain.
Points of interest
-
Relatively high weight and size considering lens size and components - not as compact as simple monoculars. Hemker&Bekking+1
-
Higher price than simple or older models.
-
Digital zoom brings loss of definition compared to optical zoom.
